Digi-Wave AIM (Advanced Interpretation Module) Transceiver

DLT 400-AIM

The Digi-Wave 400 Advanced Interpretation Module (AIM) is a portable, digital communication system specially designed for simultaneous interpretation. With Digi-Wave AIM, you can enjoy all the features of Digi-Wave 400 plus interpretation equipment features for effortless interpreting: Q&A mode for switching languages during interpreted discussions, customized channel naming, a control mode for offline programming, subgroup division, and an industry-leading 24 available channels.
5 Year Warranty Badge
Visit the Warranty and Registration page for details.

The Digi-Wave AIM Transceiver is designed to simplify simultaneous interpretation during trainings, presentations, meetings, and tours. It supports bilingual, two-way guided tours, language interpretation with Q&A, and bilingual meetings. With Digi-Wave Advanced Interpretation Mode, you can enjoy all the features of Digi-Wave 400 plus; effortless Q&A mode for switching languages during interpreted discussions, customized channel naming, a control mode for offline programming, subgroup division, and an industry-leading 24 available channels.

  • Q&A Mode – Industry unique feature enables easy Questions and Answers switching between two languages. With this device, every participant can listen and speak, enabling seamless discussions with two open microphones per language at a time. The industry-unique feature of two-way communication between the interpreter and the audience also allows audience members to ask questions back to the interpreter.
  • Custom Channel Naming – Customize room names or choose from 100 ISO language codes
  • 24 Channels – Industry-leading channel count with up to 24 channels available for interpretation
  • Control Function – The control function allows administrators to program channel names and subgroups offline and update all devices in the system when convenient for the administrator.
  • Subgroup Division–  The subgroups function allows administrators to program custom channel names and subgroups offline, making it easy for guests to identify the language they are hearing or the subgroup they belong to. Great for divisible rooms or changing group needs.

*To upgrade your current DLT 400 to include the Advanced Interpretation Features, please contact TechBlue.

System Includes

The DLT 400-AIM has an internal rechargeable battery and includes the charging pack DW ACC PAC4.

Features

  • Q&A Mode – Industry unique feature enables easy Questions and Answers switching between two languages for simultaneous interpreting
  • Custom Channel Naming – Customize room names or choose from 100 ISO language codes
  • 24 Channels – Industry-leading channel count with up to 24 channels available for interpretation
  • Control Function – Program channel naming and subgroups offline
  • Subgroup Division– Divide interpretation groups into subsets of channels. Great for divisible rooms or changing group needs.The DLT 400 has an internal rechargeable battery. Power Supply Charging Pack is sold separately.  Visit the Digi-Wave Power Supply Pack (DW ACC PAC4) product page for more information.

How It Works

Digi-Wave Advanced Interpretation Module Presentation Application

Digi-Wave Advanced Interpretation Module Meeting Application

Digi-Wave Advanced Interpretation Module Guided Tour Application

DLT 400-AIM

Dimensions 2.60”W x 4.22”H x 0.50”D

(66 mm x 107.3 mm x 12.6 mm)

Weight 3.3 oz (94 g) including battery
Color Black/Silver (Front/Back)
Case Material Black ABS plastic
Battery type Lithium Polymer with smart charge built into transceiver; 1800 mAH
Battery life Up to 16 hrs talk time per charge@ 1ch Tx and 1ch Rx
Power Save Auto Sleep Mode after 5 minutes of no RF signal from compatible devices
Charge time 5 hrs. approx.
System Voltages OLED 14VDC; RF 5VDC; Logic 3.3 VDC
Operating frequencies 2.4 GHz (ISM band); 2402 – 2476 MHz FHSS
Audio Frequency response
(-3dB Level)
Intercom Mode, Court Mode, INTP24 Mode, Q&A INTP: 100 – 7,200 Hz

Other Modes: 100 – 11,500 Hz

SNR 73 dB (A-weighted, default Rx volume with mic input )
THD 0.1 % (Default Volume, 1kHz)
Microphone input Internal microphone (disabled when MIC jack engaged) and 3.5 mm phone jack (sleeve) with electret microphone bias, adjustable gain with 63dB range.
Line Input USB-C, Adjustable level
Headphone Output 3.5 mm TRRS headphone jack; 25 mW, R 32 ohms
Audio Output Headphone: Max SSPL 90 111.8dB (EAR 013), 116.8dB (EAR 041)
Line: USB-C, Adjustable level
Range Up to 900 ft (274 m) (depending upon environmental conditions)
Modulation FSK
RF Output 19 dBm Typical
Security 87-bit encryption (300 Series Compatible), 87+128 bit Encryption, Encryption PIN, Lock for settings
Side tone -6 dB below volume, tone variation (Off, Low and High settings available)
Indicators OLED
LEDs Red LED around Talk button when enabled; Bi-color, changing green and red LED at top
Charging Connectors USB-C; Two contacts for use with CHG 412
Compatible Receiver DLR 400 RCH (with firmware 1.3.0 or greater)
Operating Temperature Range 14º to 113ºF (-10º to 45ºC)
Approvals FCC, Industry Canada, CE, RoHS 3, WEEE, RCM, ANATEL, KC, Giteki
Warranty 5 years on parts and labor with product registration; 2 years standard without registration. Internal batteries are covered for 1 year and accessories for 90 days, regardless of registration. Visit the Warranty and Registration page for details.



Warranty

5 years with registration - 2 years standard (90 days for accessories)

No Firmware Found

What is the DLT 400-AIM?
The DLT 400-AIM is a Digi-Wave 400 transceiver with the Advanced Interpretation Module, a set of features built for simultaneous interpretation. It includes everything the standard DLT 400 does, plus Q&A mode, up to 24 interpretation channels, custom channel naming, subgroups and offline programming. It’s designed for trainings, presentations, meetings and tours.

What does “AIM” stand for?
AIM stands for Advanced Interpretation Module.

How is it different from the standard DLT 400?
The hardware is the same, but the AIM adds interpretation features the standard DLT 400 doesn’t have: Q&A mode, up to 24 channels, custom channel names using ISO language codes, subgroup division and offline programming.

How is it different from the DLT 400-ACM?
The AIM is built for language interpretation. The ACM (Advanced Comms Module) is built for production intercom in broadcast, theater and live events, with features like All Call, private lines and Flexible Access Point.

What is Q&A mode?
Q&A mode makes it easy to switch between two languages during an interpreted discussion. Two microphones per language can be open at a time, so every participant can listen and speak, and audience members can ask questions back through the interpreter. It’s a good fit for bilingual meetings and two-way guided tours.

How many channels does it support?
Up to 24 channels for interpretation.

Can I name the channels?
Yes. You can give each channel a custom room name, or choose from 100 ISO language codes, so listeners can easily find their language.

What is subgroup division?
Subgroup division splits your interpretation channels into smaller sets. It’s ideal for divisible rooms or events where group needs change during the day.

Can I program the system ahead of time?
Yes. Administrators can program channel names and subgroups offline, then update every device in the system whenever it’s convenient.

What receivers does it work with?
The DLT 400-AIM works with DLR 400 RCH rechargeable receivers running firmware 1.3.0 or later. DLR 400 ALK alkaline receivers don’t support the AIM features.

Can I upgrade my existing DLT 400 to AIM?
Yes. Contact Williams AV TechBlue support to add the Advanced Interpretation features to your current DLT 400.

What comes in the box?
One DLT 400-AIM transceiver with a built-in rechargeable battery, plus a DW ACC PAC4 charging pack. To charge several units at once, add a CHG 404 (4-bay) or CHG 412 (12-bay) charger.

How long does the battery last?
The built-in 1800 mAh lithium-polymer battery runs up to 16 hours of talk time per charge, enough for a full day of sessions. A full charge takes about 5 hours.

What is the range?
Up to 900 ft (274 m). Walls, crowds and other 2.4 GHz devices can shorten it.

Is the interpretation secure?
Yes. The AIM uses digital frequency-hopping spread spectrum in the 2.4 GHz band, with 87-bit and 128-bit encryption, an encryption PIN and a settings lock, so outsiders with other equipment can’t listen in.

Does it need a license or frequency coordination?
No. It runs in the license-free 2.4 GHz ISM band. It is approved for FCC, Industry Canada, CE, RCM, ANATEL, KC and Giteki markets.

What microphone can the interpreter use?
The AIM has a built-in mic, a 3.5 mm mic jack with electret bias and 63 dB of adjustable gain, and a 3.5 mm headphone jack. The MIC 144 headset microphone is a good match for interpreters.

Can I hear myself while I talk?
Yes. Side tone plays your own voice in your headset at 6 dB below the listening volume. You can set it to Off, Low or High.

Can I connect a sound system or recorder?
Yes. The AIM has a USB-C line input and output, both with adjustable levels. You can feed in floor audio from a mixer, or record an interpreted channel.

Where can I find the manual and setup guides?
The product page includes the Digi-Wave AIM spec sheet, the Digi-Wave 400 user manual in English and Spanish, a Quick Setup Guide, a transmitter/receiver compatibility chart and a Digi-Wave comparison chart.

How big and heavy is it?
It measures 2.60″ W x 4.22″ H x 0.50″ D (66 x 107.3 x 12.6 mm) and weighs 3.3 oz (94 g) with the battery. It works in temperatures from 14° to 113°F (−10° to 45°C).

What’s the warranty?
The DLT 400-AIM is covered for 5 years on parts and labor if you register the product (2 years if you don’t). The internal battery is covered for 1 year and accessories for 90 days. Full terms are at williamsav.com/support/warranty-product-registration.

How do I get pricing?
Click “Request More Info” on the product page and the Williams AV team will follow up with a quote.
