20-Person Digi-Wave Tour Guide System

DWS TGS 20 400 ALK

This portable, wireless tour system enables a tour guide to communicate via the transceiver to as many as 20 guests using alkaline receivers.

The frequency-hopping algorithm of the Digi-Wave system ensures secure, seamless communication without any interference. This tour guide system comes with a durable carrying case for convenient transport, a headset for the guide, and earphones for guests.

System Includes

(1) DLT 400 transceiver
(20) DLR 400 ALK receivers
(1) MIC 144 headset microphone
(20) EAR 022 surround earphones
(20) BAT 010-2 AAA alkaline batteries
(1) DW ACC PAC4
(1) CCS 056 26 system carry case
(1) CCS 061 GR grey silicone skin

How It Works

20-person Digi-Wave tour guide system

BAT 010-2

Alkaline, 1.5 Volt

CCS 056 26

Interior Dimensions 13.0” W x 18.0” L x 6.7”H (33 cm W x 46 cm L x 17 cm H)
Exterior Dimensions 15.7” W x 19.7” L x 7.2” H (40 cm W x 50 cm L x 18 cm H)
Lid Inner Depth 1.5” (4 cm)
Bottom Inner Depth 5.2” (13 cm)
Approx. weight (empty) 6.6 lbs (3 kg)
Material Copolymer
Minimum Temperature -40ºF (-40ºC)
Maximum Temperature 160ºF (71.1ºC)


DLR 400 ALK

Dimensions: 2.36" W x 3.54" H x 0.63" D (60 mm x 90 mm x 16 mm)
Weight: 1.7 oz. (47 g) without batteries.
Frequency Band: 2.4 GHz (ISM band)
Modulation: FSK
Case Material: Black ABS Plastic
Battery Type: 2 x AAA Alkaline Batteries
Battery Life: Alkaline Disposable (BAT 010-2): Up to 30 hrs
Power Save: Auto Sleep Mode after 5 minutes of no RF signal from compatible devices
Audio Frequency Response: (-3dB level) Intercom Mode: 100 – 7,300 Hz Interpretation and other modes: 100-11,200 Hz
SNR: 74 dB (A-weighted)
THD: 0.1% (typical)
Antenna: Internal
Range: Up to 900 ft (274 m) (depending upon environmental conditions)
Headphone Audio Output: 3.5 mm TRRS jack with mono output for headphones, earphones, or neckloop 27 mW maximum @32 ohms
Display: LCD shows status: Battery Level, RSSI, Group/Channel #
Temp. Range: 14° – 113°F (-10° to 45°C)
Compatible Units DLT 400, DLT 300
Approvals: FCC, Industry Canada, RoHS 3, CE, WEEE, RCM, ANATEL, KC, Giteki
Warranty: 2-year warranty against component failure and manufacturing defects. See Full Warranty on the website for details
NOTE: DLR 400 ALK units are not compatible with the special AIM features.

DLT 400

Dimensions 4.22"W x 2.60"H x 0.50"D (107.3 mm x 66 mm x 12.6 mm)
Weight 3.3 oz (94 g) including battery
Color Black/Silver (Front/Back)
Case Material Black ABS plastic
Battery type Lithium Polymer with smart charge built into transceiver; 1800 mAH
Battery life Up to 16 hrs talk time per charge@ 1ch Tx and 1ch Rx
Power Save Auto Sleep Mode after 5 minutes of no RF signal from compatible devices
Charge time 5 hrs. approx.
System Voltages OLED 14VDC; RF 5VDC; Logic 3.3 VDC
Operating frequencies 2.4 GHz (ISM band); 2402 – 2476 MHz FHSS
Audio Frequency response (-3dB Level) Intercom Mode: 100 - 7,200 Hz Other Modes: 100 - 11,500 Hz
SNR 73 dB (A-weighted, default Rx volume with mic input )
THD 0.1 % (Default Volume, 1kHz)
Microphone input Internal microphone (disabled when MIC jack engaged) and 3.5 mm phone jack (sleeve) with electret microphone bias, adjustable gain with 63dB range.
Line Input USB-C, Adjustable level
Headphone Output 3.5 mm TRRS headphone jack; 25 mW, R 32 ohms
Audio Output Headphone: Max SSPL 90 111.8dB (EAR 013), 116.8dB (EAR 041) Line: USB-C, Adjustable level
Range Up to 900 ft (274 m) (depending upon environmental conditions)
Modulation FSK
RF Output 19 dBm Typical
Security 87-bit encryption (300 Series Compatible), 87+128 bit Encryption, Encryption PIN, Lock for settings
Side tone -6 dB below volume, tone variation (Off, Low and High settings available)
Indicators OLED
LEDs Red LED around Talk button when enabled; Bi-color, changing green and red LED at top
Charging Connectors USB-C; Two contacts for use with CHG 412
Compatible Receiver DLR 400 RCH, DLR 400 ALK, DLT 300 with some limitations and DLR 360 with some limitations
Operating Temperature Range 14º to 113ºF (-10º to 45ºC)
Approvals FCC, Industry Canada, CE, RoHS 3, WEEE, RCM, ANATEL, KC, Giteki
Warranty 2-years warranty against component failure and manufacturing defects. 1 year on the internal battery. See Full Warranty on the website for details.


EAR 022

Style Around-ear speaker
Plug 3.5mm mono
Cord 39"
Driver Size 23 mm
Nominal Impedance 32Ω
Freq. Response 20 - 20kHz
Weight 15g
Max Power Input 30 mW
Sensitivity 118 dB @ 1kHz


Warranty

2 Years
